BTU Meters

The heat and cooling meter Superstatic 440 is designed and optimised to measure the consumption of thermal energy in any district, heating district cooling or building management system for the individual billing of thermal energy cost and can be easily integrated in any Smart Metering environment.

• Complete range of flows 1 - 1500
  m3/h / DN 15 – DN500
• No moving parts
• Only the measuring head must
  be changed – the pipe stays in
  the system
• Same measuring head for all sizes

• Same meter for, horizontal riser
  and down pipes installation
• Corrosion resistant materials
• Stand alone, M-Bus & Radio
  communication modules options
• Energy readings in KWh, MWh,
  MJ, GJ or BTU


 Photo Credit:  Mitya Ku

On/Off Control Valves

• PopTop actuator can be placed after installation and can be removed quickly and easily for easy installation
• Easy replaceable synchronous motor
• Rugged forged brass 20bar rated body
• Manual override
• Available in 2-way or 3-way body
• Normally closed or normally open
• Wide range of CVs for better selection and control
• Spring return operation
• Available in 230, 24 & 110 VAC +-15%




 Photo Credit:  dimnikolov

Modulating Control Valves

• PopTop actuator can be placed after installation and can be removed quickly and easily for easy installation
• Rugged forged brass 20bar rated body
• Manual override
• Available as spring return or non-spring return
• Position indicator
• 24V, floating or proportional (0-10V, 0-5V, 5-10V, or 4-20mA)
• Thermoplastic enclosure
